What it delivers
The Camplux ME25B 2.5-Gallon Mini-Tank Water Heater is a mini-tank heater holding 2.5 gallons, rated at 1.44 kW on 120 volts.
Small tanks like this serve one sink or a wet bar: hot water on demand from storage, reheated between uses.
At 120 volts it plugs into or wires to an ordinary household circuit, which is why mini tanks are a common retrofit.
Other listed details: connections: 1/2" npt; material: Alloy Steel; model: ME25B.
The listing gives dimensions of 12.9 in (W) x 12.9 in (H), a weight of 6.99 kg and t&p relief valve, mounting kits, user manual in the box.
Right unit for this house?
Install it when
- One sink far from the main heater
- Wet bars, garages and offices
Look at another unit when
- Showers or whole-house use
- Long continuous draws
Strengths and trade-offs
Strengths
- 2.5-gallon tank
- 120 V
- Hot water at the tap in seconds
Trade-offs
- Runs out after its stored gallons
- Occupies cabinet space
Install limits
- Figures are the maker's or seller's own. Flow at a rise is our estimate from the input; gas, venting and electrical work needs a licensed professional.
Rated performance
Every figure below comes from the source shown in brackets. Where the maker doesn't state something, we say so instead of estimating.
| Model number | ME25B | Retailer |
|---|---|---|
| Tank | 2.5 gal | Retailer |
| Dimensions (seller) | 12.9"W x 12.9"H | Retailer |
| Features (seller) | Easy installation with cord plug, Multi-mount capability, Durable glass-lined tank | Retailer |
| Power | 1.44 kW | Retailer |
| Voltage | 120 V | Retailer |
| Product weight | 6.99 kg | Retailer |
| Material | Alloy Steel | Retailer |
| Connections | 1/2" npt | Retailer |
Rival units at this flow
More point-of-use water heaters rated for similar demand
- Westinghouse ES015A1G 1.5-Gallon Mini-Tank Water Heater
- Camplux ME40 4-Gallon Mini-Tank Water Heater
- Stiebel Eltron SHC 4 Mini-Tank Water Heater
- EcoSmart ECOMINI6 Mini-Tank Water Heater
Full point-of-use water heaters spec grid · Every Camplux unit in the catalog
Final verdict
A sensible mini-tank heater for one sink far from the main heater.
